과열기 코일 화학적인 부식을 다른 금속을 입히는 발전소 탄소강
제품 세부정보
| 애플리케이션: | 발전소 보일러와 산업용 보일러 | 재료: | 탄소강 |
|---|---|---|---|
| 상품 이름: | 보일러 과열기 | 표준: | GB, ASME, EN, IBR |
| 인증: | ISO, SGS, ASME, EN | 서피스: | 클래딩 |
| 강조하다 |
피복 과열기 코일,탄소강 과열기 코일,IBR 피복 보일러 코일 |
||
제품 설명
ASME Standard Carbon Steel Boiler Superheater with Cladding for Industrial Boilers Exported to US
Description
A superheater is a component that heats saturated steam in an industrial boiler, turning it into superheated steam. Our superheater guarantees that the superheated steam temperature will fluctuate to within an allowable range (normally varies from 540℃ to 550℃) when the boiler is over loaded.
For over 30 years, Hua Dong Boiler has been consistently innovating and improving our boiler superheaters and reheaters. The improvements in bending, welding and design ensure our products meet both European and American standards, ensuring a reliable performance.
Our company according to the requirements of customers in the boiler tube, boiler tube plate evenly surfacing a layer of wear-resistant, corrosion-resistant surfacing material. The main surfacing materials are inco622, inco625, ER309L and MG250.
1. Chemical corrosion.
2. Abrasive wear.
3. High temperature corrosion.
4. In the actual operation of various boilers, the serious thinning of the tube wall is not caused by a single factor, but is often the result of the above three kinds of corrosion. Because nco622 and inco625 materials have strong high temperature oxidation resistance, resistance to various super acid corrosion, excellent strength and toughness at high temperature, and good processability, It is usually used by customers for surfacing under complex working conditions.
Application
Use for heating saturated steam, steam temperature could be up to 900 degree C.
Superheater Capacity Upgrades to Increase Power Generation
Send us required technical data, such as steam capacity, pressure, required temperature etc. We will design accordingly.
Differences
| Type | Advantages | Disadvantages | Supporting method |
| Pendant-type | 1.Firm structural support | 1. Flow blockage by condensed steam 2. Needs slow restart to purge the water that accumulates in the bottom. | supported from above |
| Inverted-type | 1.Proper drainage of the condensed steam | 1. Lack the structural rigidity, especially in high speed gas flow | Supported from below |
| Horizontal -type |
1. Proper drainage 2. Good structural rigidity. |
1. They do not view the flam directly so they are mainly from the convective type | Usually supported in the vertical gas ducts parallel to the main furnace. |
